| Feature: | Bridge Crane |
|---|---|
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Warranty: | 12months |
| Certification: | ISO |
| Model Number: | LX type Motor-driven Single Beam Bridge Crane |
| Place of Origin: | China (Mainland) |
| Span: | 3-16 m, customized according to clients' requirement |
| Max. Lifting Height: | 6-30m |
| Rated Loading Capacity: | 0.5-5MT |
| Application: | workshop, warehouse etc. |
| Condition: | New |
Quick Details
Specifications
feature:
1.high electrical protection ;
2. explosion proof ;
3.suitable for inflammable and explosive field ;
3.the color can be paint according to requirement
4.the main beam can be cut off, convenient for transportation.
5.manufacturing period is short.
6.the crane can be customized according to special parameter.
technical parameter
LX Explosion Proof Single Girder Crane is an explosion proof crane.It is improved and designed on the basis of LX model.It is characterized by more reasonable
structure and higher strength steel as a whole. Used with CD1 model electric hoist as a complete set. It is a light
duty crane with a capacity of 0.5 to 5 tons. The span is 6-31.5 m. Working grade is A3. Working temperature is -25℃ to
40℃.
1.high electrical protection ;
2. explosion proof ;
3.suitable for inflammable and explosive field ;
3.the color can be paint according to requirement
4.the main beam can be cut off, convenient for transportation.
5.manufacturing period is short.
6.the crane can be customized according to special parameter.
technical parameter
| Lifting Weight(t) | 0.5 , 1 , 2 , 3 | 5 | |||||
| Ex-mark | d ⅡBT4 | ||||||
| operation mode | ground control | ||||||
| crane travelling mechanism | working speed (m/min) | 20 | 20 | ||||
| motor | type | BZDY | |||||
| power/Kw | 2×0.4 | 2×0.8 | |||||
| rotational speed r/min | 1380 | ||||||
| lifting mechanism (electric hoist)& electric hoist travelling mechanism | electric hoist | BCD | |||||
| lifting speed v1(m/min) | 3.5 | ||||||
| lifting height H(m) | 6 9 12 18 24 30 | ||||||
| moving speed v2(m/min) | 20 | ||||||
| working system | A3-A5 | ||||||
| electric current | three-phase 380 50 HZ(according to requirement) | ||||||
| wheel diameter | Φ130 mm | Φ150 mm | |||||
| I-Beam(GB706-65) | I120a～I36c | I128a～I45c | |||||
LX Explosion Proof Single Girder Crane is an explosion proof crane.It is improved and designed on the basis of LX model.It is characterized by more reasonable
structure and higher strength steel as a whole. Used with CD1 model electric hoist as a complete set. It is a light
duty crane with a capacity of 0.5 to 5 tons. The span is 6-31.5 m. Working grade is A3. Working temperature is -25℃ to
40℃.
LX model single beam motor crane is widely used in plants, warehouses, and material stocks to lift goods. It is prohibited to use the equipment in the
combustible,explosives environment.
The product has two operational methods: ground(remote) control and cab operation. The cab can be opened or closed, and
can be installed on the left or right side according to situation. The door of the cab has two directions to entering: side and end.
According to the used condition, it can be selected.
