Die Tryout Machine is a type of the multifunctional and convenient mold inspection machine. Our Die Trying Machine can be equipped with Electro-permanent magnetic chuck, which can easily control the mold titling and place so precisely.



1.Introduction:

Product Name:Die Tryout Machine

Model No.:HMG-70S

Brand:SXKH



2.Advantages:

-1.It can be equipped with Electro-permanent magnetic chuck on fixed and movable plates to fix the mold in the unit so rapidly.

-2.Really simply for mold repair and mold try service.

-3.Mold shall be tilting 90 to 108 degree.

-4.Demould, high pressure of water path testing and mold fixing are automatically completed,which are all controlled .

-5.Custom made is accepted upon the customer's usage and requirement.



3.Patent No.:20140266674.1 201420266673.7 201420266102.3

Parameters
Item	Unit	Parameters
Clamping force	KN	55
Opening force	KN	50
Overturn A Ejecting Force	KN	110
Overturn B Ejecting Force	KN	55
Demold Ejecting Force	KN	30
Demold Ejecting distance	mm	210
Mold dimension	mm	1000*800
Overturn degree	°	90/180
Remove range of mold	mm	500
Die open/close speed	mm/s	60/40
Overturn speed	°/s	8
Max weight of mold	Kg	8000
Machine size	mm	3400*880*1680
Machine weight	Kg	3100
