| Chemical Composition: | Fe3O4 |
|---|---|
| Material: | concentrate iron |
| Shape: | powder |
| Application: | brake pad Drum brake or clutch |
| Model Number: | 200mesh 325mesh |
| Brand Name: | Daye Jinpeng |
| Place of Origin: | China (Mainland) |
| density:: | 4.5-5.2g/cm3 |
| Fe3O4 content:: | 80% min |
| moisture:: | 2%max |
| grade:: | 200mesh,325mesh |
| sieving rate:: | 98% |
Quick Details
Specifications
Product description:
Concentrate iron is powder,the main content Is Fe3O4.the mohs hardness is 5.5, the density is 4.5- 5.2 g/cm3. ,the melting point is 1539 centigrade and the boiling point is 2740 centigrade. Concentrate iron is made by Selected and crushed magnetic iron ore,it can be used to adjust the temperature Coefficient of friction and reduce the heat recession.
It can Clean the friction couple in the high temperature to increase the Efficiency of the brake and reduce the cost.
It can be used in brake pad Drum brake or Clutch. and the recommended regular consumption is 2%—8%.
the character of concentrate iron:
Iron in nature is mainly of the iron oxide and sulfide, and are mainly of divalent and trivalent, and trivalent compounds Is the most stable. Magnetic iron ore is the most important basic structural Material.Almost all large scale iron ore in China are rich in elements, for Example, panzhihua iron ore containing rare earth; daye iron mine Containing Copper, cobalt and gold; DaDingShan iron ore containing tin, etc.Ferroferric Oxide (black) can improve the friction function of final product and have Shading effect
:
Density: 4.5-5.2g/cm3
Fe3O4Content: 80% min
Screen analysis: +S 200 95%min
-S 100 100%
