Description:
Specifically designed for surgical locations wherever space is limited, such as dental anesthesia, shipboard or craft, etc.
Fully operated by Manual, no electricity will be required,
With handle on it and soft feet-mat under it, movable to any place,
Classical CO2 circle absorber is with 1 canister, low resistance, minimum gas leakage,
More choices for clients, with or w/o Ventilator,
Gas supply: O2, O2+N2O, O2+ Air
Optional: Anesthesia Ventilator with LCD display or with LED display
Applications:
The Anesthesia Machine which is researched and produced by the Manufacturer Readeagle is a movable unit with anesthesia function , which could be applied to closed anesthesia, semi-closed anesthesia, and semi-open anesthesia, and be applicable to Adult / Pediatric inhalation anesthesia, oxygen supply, resuscitation.
Specifications:
Competitive Advantage:
Specifically designed for surgical locations wherever space is limited, such as dental anesthesia, shipboard or craft, etc.
With handle on it and soft feet-mat under it, movable to any place,
Classical CO2 circle absorber is with 1 canister, low resistance, minimum gas leakage,
More choices for clients, with or w/o Ventilator,
Gas supply: O2, O2+N2O, O2+ Air
Optional: Anesthesia Ventilator with LCD display or with LED display
Specifically designed for surgical locations wherever space is limited, such as dental anesthesia, shipboard or craft, etc.
Fully operated by Manual, no electricity will be required,
With handle on it and soft feet-mat under it, movable to any place,
Classical CO2 circle absorber is with 1 canister, low resistance, minimum gas leakage,
More choices for clients, with or w/o Ventilator,
Gas supply: O2, O2+N2O, O2+ Air
Optional: Anesthesia Ventilator with LCD display or with LED display
Applications:
The Anesthesia Machine which is researched and produced by the Manufacturer Readeagle is a movable unit with anesthesia function , which could be applied to closed anesthesia, semi-closed anesthesia, and semi-open anesthesia, and be applicable to Adult / Pediatric inhalation anesthesia, oxygen supply, resuscitation.
Specifications:
| Ventilation Volume | 20 ~ 1500ml |
| Flowmeter |
O2: 0.1~10L/min. N2O(Air): 0.1~10L/min. |
| APL valve | 0.5~6.0Kpa |
| O2 Flush | 25~75L/min. |
| Volume of soda lime tank (CO2 absorbing tank) | 1000ml |
| Gas supply | O2 or O2+ N2O or O2+ Air |
| Gas Supply pressure: |
O2: 0.25~0.65Mpa N2O(Air): 0.25~0.65Mpa |
|
Physical specification |
Whole machine: Length:380mm Width: 200mm Height: 350mm Weight: 16.5Kg (including Vaporizer) |
|
Environments |
Temperature: Working: 18-36oC Storage: -20-55oC Comparative humidity: Working: 45%-75% Storage: ≤93% Atmosphere: Working: 0.95~1.05 bar Storage: 500hpa~1060hpa, Altitude: Working: 500 to 800 mmHg (3565 to -440m) Storage: 375 to 800 mmHg (5860 to -440m) |
Competitive Advantage:
Specifically designed for surgical locations wherever space is limited, such as dental anesthesia, shipboard or craft, etc.
With handle on it and soft feet-mat under it, movable to any place,
Classical CO2 circle absorber is with 1 canister, low resistance, minimum gas leakage,
More choices for clients, with or w/o Ventilator,
Gas supply: O2, O2+N2O, O2+ Air
Optional: Anesthesia Ventilator with LCD display or with LED display
