| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Warranty: | 12months after installation |
| Certification: | CE |
| Weight: | 20mt |
| Dimension(L*W*H): | 20m*3m*2m |
| Power(W): | 15KW |
| Voltage: | 380V or 440V |
| Model Number: | SI-TM-S00 |
| Brand Name: | Serphitech |
| Place of Origin: | China (Mainland) |
| Production Capacity: | 10Mt/day |
| Application: | Energy Supply Pipe |
| Pipe Material: | Stainless Steel |
| Type: | Pipe Mill |
| Condition: | New |
Quick Details
Specifications
I Main technical specification
1, Raw material request
Material of strip: stainless steel strip
Strip OD: 900mm-φ1600mm
Strip ID: φ508mm
Width: 38-120mm
Thickness: 0.4—1.5mm
Strip weight: Max 2.0Mt (2000kg)
2, Pipe size:
Diameter: φ12.7～φ38mm
Wall thickness: 0.4～1.5mm
3, Layout:
Form: Separated type
Disposal: Feeding from side (the location of control desk will be decided by customer)
4, Speed: 4—10m/min
II Technology process
Uncoiling->Shearing and butt welding->Leveling->Forming unit->Argon arc welding->Outside seam polishing->Sizing unit->straighting ->Flying saw->Semi-finishTransport->online polishing for all pipe->Run-out table
III Equipment List
|
No |
Equipment Name |
Supplier |
Unit |
Qty |
|
1 |
Double uncoiler |
|
Set |
1 |
|
2 |
Shearing and butt welding |
|
Set |
1 |
|
3 |
Main forming unit |
|
Set
|
1
|
|
Welding parts |
||||
|
Outside seam polishing |
||||
|
Sizing unit |
||||
|
4 |
Argon welder |
Panasonic |
Set |
1 |
|
Cooling system for argon welder |
|
|
1 |
|
|
5 |
Flying saw |
|
Set |
1 |
|
6 |
Semi-finish transport |
|
Set |
1 |
|
7 |
Online polisher |
|
Set |
1 |
|
8 |
Run out table |
|
Set |
1 |
|
9 |
Roller |
|
Set |
1 |
|
11 |
Emulsion Circulatory system (For main forming unit) |
|
Set |
1 |
|
12 |
Dust pelletizing system for polishe |
|
Set |
1 |
