| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Certification: | ISO9001 |
| Weight: | 700kg |
| Dimension(L*W*H): | 1130*1010*1900mm |
| Power(W): | 3.5KW |
| Voltage: | 3 plase 380V |
| Model Number: | DM703 |
| Brand Name: | Zhonghang Changfeng |
| Place of Origin: | China (Mainland) |
| CNC or Not: | CNC |
| Condition: | New |
Quick Details
Specifications
Specification and Parameters
ITEM |
DM703 |
DN703 |
Work table size(L×W) mm |
460×350 |
580×400 |
Work table travel (X×Y) mm |
400×300 |
500×400 |
Z axis travel mm |
300＋250 |
300＋300 |
Drilling depth mm |
300 |
300 |
Max drilling speed (mm/min) |
60 |
60 |
Max working current A |
30 |
30 |
Diameters of Electrodes mm |
0.2-3.0 |
0.2-3.0 |
Load of table kg |
300 |
300 |
Working solution |
Water |
Water |
Working reservoir capacity L |
30 |
30 |
Rated Voltage (customizable) |
380V/50Hz |
380V/50Hz |
Max power comsumption KW |
3.5 |
3.5 |
Machine weight Kg |
700 |
900 |
2nd travel control type |
Manual |
Manual |
Digital display |
Three axis |
Three axis |
Function of setting depth |
Yes |
Yes |
Machine dimensions mm |
1130×1010×1900 |
1350×1400×1800 |
