DX-150 Intelligent Digital Gauss Meter / Tesla Meter

DX-150 Full-Digital Gauss/Tesla Meter is designed for applications requiring high precision, high-resolution magnetic field measurement. It is an intelligent solution against the traditional analog, digital table header type Gauss / Tesla meter. It is a high precision intelligent apparatus, which integrates measuring, storage, industrial control, communication just in one machine. DX-150 takes advantage of microprocessor technology to provide you with high-precision, higher refresh rate and display resolution and high measurement repeatability and stability in your research and production.With simple and convenient operation panel and the full menu, 4 ?-bit resolution readings, a high-resolution 1 / 60000, so that you can view 0.1Gs weak changes in the high magnetic field measurement. It has a maximum range up to 30KG (3T). It has a large capacity of data storage and you can review data according to storage time. In one word, it is suitable for a full range of DC magnetic field measurements, and it is mainly sold to research institutes and various types of production units.

Industrial interface can be installed if needed.

Features

4 ?-bit resolution on wide-screen LCD panel	Auto-zero, automatic/manual range
Maximum/ minimum/ interface locking	RS-232C interface
Display units optional Gauss or Tesla	Threshold setting and alarming
Probe auto calibration	Dozens of optional basic or customized probes
Communication baud rate adjustment	Standard 1.00mm ultra-thin consistency probe
Data-storage(auto/manual)/Historical-data reviewing	Time setting/ Temperature display



Specifications

Model-150 Specifications
	0.1mT=1Gs
Range	(0.1Gs-3000Gs)/( 1Gs-30KG)
Resolution	0.1Gs(0.01mT)
Accuracy (display value)	DC	±0.3% of reading ±0.05% of range
	AC	±2.0% of reading ±0.5% of range
Frequency Range	DC mode	DC
	AC mode	AC20Hz to 20kHz
Additional effects	Temperature coefficient	±(0.03% ±1 count)/ oC
Temperature range	Working temperature	0oC to 50oC
	Storage temperature	-10oC to 60oC
Panel display	128 * 64 pixel, widescreen LCD
Communication Interface	RS-232   Standard 9-pin D-type connectors
Supply power	Voltage: 200/240v  Frequency: 50-60 Hz

Peripheral: computer, oscilloscope, industrial equipment, bus system

Using occasions

Permanent magnet material surface magnetic field, DC motors, speakers, magnetic separator, and permanent magnetic separator magnetic field of work. Magnetic circuit gap and slit field within the magnetic field. Also it can be applied to the detection machining residual magnetic field of the goods, distribution of magnetic field, the remaining magnetic after demagnetization, the magnetic of motor and magnetic flux leakage of electromagnetic fields and other kinds of magnetic field intensity of magnetic induction.

Main Function

*High –precision magnetic field measurement

* Automatic / Manual Storage: This machine provides 500 data storage space and automatically store data according to set time (1-60 seconds). Also it provides random storage and can be reviewed as per time and stored order.

*Max / Min Lock: Turn on or off the peak measurement function.Capture and display the highest and the lowest magnetic field readings, and lock the interface.
First gear : Maximum/minimum holding
Second gear: interface locking
Third gear: relieving

*Auto zeroing mode
1)relative zero magnetic field mode: put the probe into chamber of Zero-Gauss calibrator, zeroing and store the data.
2)eliminate geomagnetic field mode: horizontally put the probe make sure it isto be vertical against geomagnetic field, zeroing and store the data.

*Communications and drawing:
The RS-232C interface function
1) the user can use the computer to read test data, draw various survey map with professional mapping software, and transmit and print chart
2) with serial real-time transmission function of real time monitoring real-time data in a computer
3) query real-time data through fixed instruction



DX-150 optional accessories

Remote control system
Gauss meter professional mapping software
Zero Gauss chamber
Industrial control output components
