Electrical
Frequency Range      698-960/1710-2700MHz
Band width       262/990MHz
Gain     7/10dBi
F/B Ratio     15/20dB
V.S.W.R      ≤1.8
Radiation      Direction
Horizontal Beam width     70°/75°
Vertical Beam width        75°/60°
Polarization      ±45
Maximum Input Power      50W
Impedance     50?
Connector      2XN Female
Cable Type     RG58U
Cable Length     30cm
Antenna Radome Material     ABS
Mount way      Pole mount/Wall mount
Diameter of Installation Pole     ?30~?50mm

Mechanical
Dimensions     300x183x70mm
Weight     1.37KG
Operating Temperature     -40℃ to+60℃
RoHS Compliant     YES
