Description:
1. INPUT SPECIFICATIONS
Input voltage 90 - 264Vac
Input frequency 47 - 63Hz
Input current 100 - 115V / 10.1 - 8.6A
115 - 127V / 9.1 - 8.2A
200 - 240V / 5.2 - 4.4A
2. GENERAL SPECIFICATIONS
Hold-up time 11ms @ 70% Load
Efficiency 94% @ 50% Load
MTBF 200,000 hours at 25 degree C
3. ENVIRONMENTAL SPECIFICATIONS
Temperature 0 to 50 degree C Operating
Altitude 16,500 feet Operating
Relative humidity 20% to 85% RH Operating
1. 80 PLUS Platinum
2. Support PMBus 1.3
3. Internal ORing
4. N+1 Redundant
5. Digital Power Supply
6. Cold Redundancy
7. Smart Ride Through
8. Black Box Recorder
9. Automatic Firmware Update
10. High Power Density 28.1 W/in3
11. Active Power Factor Correction
12. Intel Standard CRPS Form Factor
13. Closed Loop System Protection (CLST)
1. INPUT SPECIFICATIONS
Input voltage 90 - 264Vac
Input frequency 47 - 63Hz
Input current 100 - 115V / 10.1 - 8.6A
115 - 127V / 9.1 - 8.2A
200 - 240V / 5.2 - 4.4A
2. GENERAL SPECIFICATIONS
Hold-up time 11ms @ 70% Load
Efficiency 94% @ 50% Load
MTBF 200,000 hours at 25 degree C
3. ENVIRONMENTAL SPECIFICATIONS
Temperature 0 to 50 degree C Operating
Altitude 16,500 feet Operating
Relative humidity 20% to 85% RH Operating
