Operate voltage (23℃)
|
DC:≤75%*Rated voltage
|
|
/
|
|
Release voltage (23℃)
|
DC:≥10%*Rated voltage
|
|
/
|
|
Maximum voltage (23℃)
|
110%*Rated voltage
|
|
Normal coil voltage
|
DC
|
3-48V
|
|
AC
|
/
|
|
Normal coil power
|
DC
|
0.36W(0.45W,0.54W)
|
|
AC
|
/
|
|
Pick-up time
|
≤10ms
|
|
Release time
|
≤5ms
|
|
Dielectric strength
|
between Same-pole contacts
|
750VAC/1min(leakage current 1mA)
|
|
between Opposite-pole contacts
|
|
|
between contacts and coil
|
1500VAC/1min(leakage current 1mA)
|
|
Insulation resistance
|
≥100mΩ(500VDC)
|
|
Ambient temperature
|
-55℃ ～70℃
|
|
Ambient humidity
|
35%-80%RH
|
|
Atmospheric pressure
|
86-106KPa
|
|
Shock resistance
|
10G (sinusoidal half-wave pulse: 11ms)
|
|
Vibration resistance
|
10-55Hz (double amplitude: 1.5mm)
|
|
Installation
|
PCB
|
|
Packing
|
Inner box
|
Plastic pipe
|
25PCS
|
|
Foam box
|
100PCS
|
|
Outer box
|
Plastic pipe
|
2000PCS
|
|
Foam box
|
1000PCS
|
|
Dimension of the carton
|
2000PCS CTN
|
420*235*230MM
|
|
1000PCS CTN
|
295*205*300MM
|
|
Weight
|
1PC
|
Approximate 10g
|
|
2000PCS CTN
|
G.W:21KG N.W:20KG
|
|
1000PCS CTN
|
G.W:10.5KG N.W:10KG
|
|
|
|
|
|
|
|
