Operating mode
1. B,B/B,4B mode
2. M,B/M mode
3. CFM
4. PDI
5. PW
6. CW
7. THI

Image processing introduction
Acoustic  beam  processing
Full digital acoustic beam technology, real time point-to-point dynamic receiving focus, continuous dynamic focus, real time
Dynamic adjustable variable aperture imaging technology,real time dynamic acoustic beam apodization, dynamic filtering, numerical
Control dynamic frequency scanning

Image Pre-treatment
Gain:0~100 dB
TGC:8 stages TGC
Acoustic output(power adjustable):High,Middle,Low
Digital channels:24

Image processing
IE:0~4
Frame correlation:0~5
IP(gamma correction):0~8
Compressing curve:0~15
Scanning parameters

B Mode:
1.B acoustic output:High,Middle,Low
2.B Gain:0~100
3.Depth arrange: Different probe has different depth and adjustable step number
4.Dynamic:0~120Db
5. Scanning:higher frame rates, high density
6.Frequency conversion:5 classes
7.Harmonic wave: adjustable

 M Mode:
       1.M acoustic output:High,Middle,Low
       2.M Gain:0~100
       3.Depth arrange: Different probe has different depth and adjustable step number
       4.Dynamic:0~120dB
       5.M scanning speed:High,Middle,Low
       6.M sample line: visual and adjustable
       7.M work mode:roll,scan
       8.Scanning:higher frame rates, high density
       9.Frequency conversion:5 classes
      10.Harmonic wave: adjustable

CFM Color Dopplar Mode,PDI Pow Dopplar Mode:
      1.Power adjustable:High,Middle,Low
      2.CFM gain:0~100dB
      3.Frequency conversion: 5 classes
      4.Max PRF:7.5kHz
      5.Min PRF:0.35kHz
      6.CFM wall filter:8 stages 50-350Hz
      7.Sensitivity: 6 kinds
      8.Color persistence:3steps
      9.Color threshold:6 kinds
     10.Color balance:16steps
     11.Color smooth:3steps
     12.Artifact remove:2 steps
     13.Linear color steering adjustable
     14.Image optimization:12calsses

PW Spectrum Doppler Mode
     1.Power adjustable:High,Middle,Low
     gain:0~100dB
     dynamic:0~120dB
     frequency:adjustable
     wall filter:8 stages50-350Hz
     6.Velocity scale:adjustable
     7.Sample volume width:adjustable
     8.Corrected angle
     9.Baseline adjust:adjustable
    10.Volume:adjustable
    11.Linear color steering adjustable
     1.BPD:10 kinds formula
     2.CRL:7 kinds formula
     3.GS:4 kinds formula
     4.FL:10 kinds formula
     5.HL:3 kinds formula
     6.TAD:1 kind formula
     7.TTD:1 kind formula
     8.APTD:1 kind  formula
     9.HC:5 kinds formula
    :6 kinds formula
     11.FT:2 kinds formula
     12.LV:1 kind formula
     13.THD:1 kind formula
     14.TCD:1 kind formula
     15.OFD:2 kinds formula
     16.EFW:12 kinds formula
     17.BSA:5 kinds formula

Probes
