| Item |
Specification |
Item |
Specification |
| Input Frequency Range |
Low Band:10.70~11.70GHz
High Band:11.70~12.75GHz |
L.O. Phase Noise |
-50dBc/Hz@1KHz
-75dBc/Hz@10KHz
-95dBc/Hz@100KHz |
| Output Frequency Range |
Low Band:950~1950MHz
High Band:1100~2150MHz |
Image Rejection |
40dB(Min.) |
| Noise Figure |
Low Band:0.6dB(Typ.)
High Band:0.6dB(Typ.) |
Output VSWR |
2.0:1(Max.) |
| Conversion Gain |
60dB(Typ.) |
Output Power |
0dBm (Min.)(at 1dB gain compression) |
| Gain Flatness |
±0.5dB/26MHz |
Connector Type |
75Ω Female Connector |
| Cross POL. Isolation |
25dB(Typ.) |
DC Current Consumption |
80mA(Typ.) |
| L.O. Frequency |
Low Band:9.75GHz
High Band:10.60GHz |
Low/High Band Switching |
Low Band:0Hz
High Band:22KHz±4KHz |
| L.O. Frequency Stability |
±1.0MHz(Max.)@+25°C
±2.0MHz(Max.)@-30°C~+70°C |
POL. Switching Voltage |
10.5~14.0V @VP
16.0~20.0V @HP |
| Operating Temperature |
-30°C~+70°C |
Adjustable Distance Range |
0~37mm |
