Along with wire diameter and mesh density, another important parameter in design and operation is the vapor velocity. This can be controlled by careful selection of the mesh area. Optimal area will depend on operating temperature, pressure and pressure drop. Under normal operating conditions, 99% + removal efficiency can be achieved with a pressure drop of less than 250 Pascals.

Wire Size: 0.08mm - 0.30mm flat wire or round wire. Single-strand knitted, multi-strand knitted, metal & non-metal (various fibers) knitted wires may be pressed into various specification of corrugated wire as require.

Type Specification:
Standard type 40-100  60-150 105-300   140-400  160-400  200-570
High-efficiency type 60-100  80-100 80-150 90-150 150-300 200-400 300-600
High-penetration type 20-100 30-150 70-400 100-600 170-560
Damping type 33-30 38-40 20-40 26-40 30-40 30-50 48-50 30-60 30-80 50-120
or according to your demands

Construction materials:
SUS304, 304L, SUS316, 316L, Copper, Nickel, Titanium, MONEL, P.P (Poly propylene), P.E (poly ethylene), teflon and glass fiber

Packaging Details:
Plastic bag inside, carton or wooden case outside.

Delivery:
10-15 days after received your payments.

Benefits:
1 Easy to install in all process equipment
2 Most cost-effective solution when equipment sizes are set by other requirements
3 High efficiency with low pressure drop
4 Emergency delivery available
5 ISO9001:2008

Applications:
Knockout Drums, Distillation Towers, Steam Drums, Absorbers, Sulphuric acid plants, Vacuum columns, Evaporators, Disitllation and rectification plants, Oil separators and etc
