Production parameter

Bit Type	6" GM1304TZ
IADC Code	M233
Blade	4
Cutter Size (mm)	Φ13MM; Φ10MM
Cutter Qty	Φ13×27; Φ10×4
Nozzle Qty/Type	4NZ
Gauge Length (mm)	76
Connection	3-1/2" API REG
N.W./ G.W.(KG)	27/37
Nozzle Size (inch)	14/32

1.GREAT PDC bit Advantage



Equipped for Performance  Great PDC Bits are equipped with
1.High AbrasionTungsten carbide material.
2.High performance PDC-Cutters.
3.Carbide and Diamond gauge protection.
4.Carbide/Diamond Shock Studs.
5.Threaded or Plain Carbide Nozzles for Flushing.



GREATBIT CHARACTER

1. Force balanced, resist impact to the blade during high-speed drilling, to make bit work stable.

2. Plus wear knot section, reduce collision in the high-speed rotational vibration.

3. Patented matrix formulation, extended bit life.

4. Optimal hydraulic design, easy to move out the drill cuttings and cooling.

5. Equipped with back reaming teeth.

6. the cutter is high performance to increase the ability of anti-impact and anti-abrasive.

2.Production Process

 Matrix body

Matrix body fixed cutters are made from tungsten carbide material. this provides improved wear resistance and erosion.Additionally, they are typically more heavy set as far as cutter applications of high fluid volume or high sand, matrix body bits offer longer life and multiple bit runs.

GREAT Size &PArameter Available  : 3inches -26inches

PDC Cutter manufacture:

We had very good relationship with the PDC Cutter factory in the world,like USS,E6,Smith; and discuss the cutter technology and long term cooperation and relationship. so that we can improve our PDC drill bits performance, drilling faster and lower cost.
