| Model No.: SP014 |
| System |
Main Processor |
HD processor,built-in ARM9 and a high-speed video co-processor. |
| Operating system |
Embedded Linux OS |
| Image Sensor |
Sensor |
High Definitioin Color CMOS Sensor |
| Display Resolution |
1280*720 (1.0 Megapixel) |
| Min.Illuminatioin |
0.1 Lux / F1.2 (with IR Illuminator) |
| Lens |
Lens Type |
Glass Lens |
| Lens Parameter |
Focal Length:3.6 mm; Aperture:F 2.4 |
| Angle of View |
75° |
| Video |
Image Compression |
H.264. |
| Image Frame Rate |
30fps maxmium, downward adjustable |
| Resolution |
720P(1280 * 720), VGA(640 * 360), QVGA(320 * 180) |
| Infrared Mode |
Automatic |
| Night Visibility |
35 Pcs LED, IR distance up to 15 meters |
| Filter Switch(IR-Cut) |
Built-in IR Cut, no color deviation indoor or outdoor. |
| Network |
Ethernet |
RJ-45 Ethernet |
| Wireless |
Standard IEEE 820.11 b/g/n, Security support :WEP, WPA, WPA2 Encryption. |
| Online Visitor |
Online Visitor LAN support 10 people, WAN support 5 people. |
| Onvif |
Support Onvif Protocol, Support NVR (above Onvif version 2.4.2) |
| Alarm |
Alarm |
Support Motion detetion alarm, Phone push alarm. |
| Others |
Product Type |
Metal Gun type / Waterproof outdoor use |
| DC Power |
DC12V/1A.. |
| Working Temperature |
-10～60℃ |
| Working Humidity |
10%- 90% RH |
| Size |
Item size: 100mm*66mm*73mm (L*W*H) |
| Packaging size:182mm*110mm*149mm(L*W*H) |
| Weight |
N.W.:310g G.W.: 610g (Note:Actual Weight Final) |
| Accessories |
Adaptor, User Manual, Bracket,Screw. |
System
Required |
for APP |
Support iOS and Android system smart phone or tablet PC. |
| for PC |
Support Internet Explorer(IE), Firefox, Google (below 42 version) browser remote monitor. |
| Certification |
CE,FCC,RoHS |
| Warranty |
Limited 2-Year Warranty |
