| Wire Gauge: | 2-3mm |
|---|---|
| Material: | Galvanized Iron Wire |
| Aperture: | 60x80mm,80x100,100x120mm etc |
| Hole Shape: | Hexagonal |
| Application: | Gabions |
| Type: | gabion box |
| Material: | Low-Carbon Iron Wire |
| Model Number: | HT-hg001 |
| Brand Name: | HT |
| Place of Origin: | China (Mainland) |
| Commodity: | gabion box |
| Mesh: | 60x80mm,80x100,100x120mm etc |
| Wire: | 2-3mm |
| Size: | 2m x 1m x 1m, 3m x 1m x 1m, 4m x 1m x 1m, 2m x 1m x 0.5m, 4m x 1m x 0.5m. |
| Material: | low carbon steel wire |
| Surface: | hot-dipped galvanized, galvanized aluminum alloy or PVC coated, |
Quick Details
Specifications
Gabion box
We design and supply gabion boxes made of heavy hexagonal wire nettings.
Gabions sizes: 2m x 1m x 1m, 3m x 1m x 1m, 4m x 1m x 1m, 2m x 1m x 0.5m, 4m x 1m x 0.5m. Custom orders available.
It can be hot-dipped galvanized, galvanized aluminum alloy or PVC coated, etc.
| Hexagonal Wire Netting Gabions | |||
| Opening (mm) |
Wire Diameter(Metal Wire) (mm) |
Wire Diameter (PVC Coate)/ Inner/Outside(mm) |
Strands |
| 60X80 | F2.0-2.8 | F2.0/3.0-2.5/3.5 | 3 |
| 80X100 | F2.0-3.2 | F2.0/3.0-2.8/3.8 | 3 |
| 80X120 | F2.0-3.2 | F2.0/3.0-2.8/3.8 | 3 |
| 100X120 | F2.0-3.4 | F2.0/3.0-2.8/3.8 | 3 |
| 100X150 | F2.0-3.4 | F2.0/3.0-2.8/3.8 | 3 |
| 120X150 | F2.0-4.0 | F2.0/3.0-3.0/4.0 | 3 |
