| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Warranty: | 1 year |
| Certification: | CE,HACCP,ISO |
| Weight: | 650KG |
| Dimension(L*W*H): | 5500*1280*1800mm |
| Power(W): | 4.11KW |
| Voltage: | 380v |
| Model Number: | SD-X-300 |
| Brand Name: | Cryogenic |
| Place of Origin: | China (Mainland) |
| Type: | Tunnel Freezer |
| Condition: | New |
| Lowest temp: | -150C |
| Cooling rate: | 1-20C/min |
| Freezing time: | 8-12 minutes |
| Refrigeration: | Liquid nitrogen |
Quick Details
Specifications
-196 °C, 5 Minutes quick freezing, the future of frozen food.
the best way to keep the original looks, taste and cells structure
the temperatures of Liquid nitrogen is -196 °C, which is the most ideal refrigeration medium. When it is in contact with food, the nitrogen gas will be able to take the Heat of the food away in only few minutes, which maximally preserves the moisture and keep the original taste, looks and cells structure of the food. the ice crystal inside is very tiny and even, which will not break the cells after defrost and the weight loss is only 0.5%. Nitrogen gas is colorless, odorless, nontoxic, which also much safer than R22,R717,R404.
2. Technical parameters:
| Description | Liquid nitrogen chiller, flash freezer |
| Material | 304 stainless steel |
| Size | 5500*1280*1800mm |
| Belt size | 4800*900mm |
| Lowest temperature | -150C |
| Cooling rate | 1-20C/min |
| Capacity | 300kg per hour |
| Power | 4.11KW |
| Voltage | 220/380V |
| Language | English interface |
3. Application:
the freezer is Used for freezing vegetables ( A variety of vegetables including Green peas, corn, Green beans, fried or boiled potatoes, carrots or sliced mushrooms, cauliflower, peppers, tomatoes, cabbage and cut into pieces, sheets, strip ), fruits ( Apple slices, pineapple slices, strawberries, blackberries, cherries, Marin fruit, plums, apricots, Purple berries, grapes) and meats ( Pork, beef, mutton, fish fillets, fish sticks, shrimp, Seafood)
4. Product Advantages:
A. the freezer uses liquid nitrogen refrigeRant, green and safe.
b. the lowest temperature: -150°C,tHe freezing rate is up to 20°C/min.
c. Food grade stainless steel belt conveyor, good low temperature resistance. the heat insulation layer is120mm
d. Simple operation, PLC+ touch screen control, Chinese/english dual language, real time monitering the tenperature and cooling curve.
E. Factory customized cooling fans, long time service life, and keeps the temperature uniformity.
F. Special designed cleaning and maintenance door, easy for inside cleanning.
G. Multi point liquid nitrogen injection, ASCO control vavle, the consumption of liquid nitrogen is quite low, and
the temperature is even inside.
5. Company Profile:
Cryogenic (Beijing) Science & Technology Co.,Ltd, was founded in 2008, the pioneer of ultra low temperature liquid nitrogen system in China. Now we have the largest liquid nitrogen freezer workshop in China. We never stop innovation and improvement. Which makes us the market leader in the liquid nitrogen freezing system and frozen food machinery industry.
