| Classification: | Laboratory Heating Equipments |
|---|---|
| Place of Origin: | China (Mainland) |
| Model Number: | STM-30-12 |
| Brand Name: | Sante |
Quick Details
Specifications
Main fearures:
1. Furnace chamber is made of high purity Al2O3 ceramic fiber materials, no powder dropping off under high temperature, low heat capacity, and high efficiency of energy saving.
2. Dual-layer case structure, lower external temperature.
3. Microcomputer PID control module enables precise temperature control and constant temperature requirements.
4. Temperature contrOller is programmable with 2 groups/16 segments, and avaiable to set temperature curve.
5. over-temperature alarm: wheN temperature exceeds the limit value, machine will send out light-sound signal and stop heating.
Specifications:
Optional components:
1. A large screen paperless recorder, to achieve real-time temperature curve recorded with a memory card of experimental data analysis and printing.
2. Installation of an air intake, which can feed into air and inert gas. An exhaust chimney connecting stainless steel bellows, so that the generate toxic gas emissions to a specified location.
1. Furnace chamber is made of high purity Al2O3 ceramic fiber materials, no powder dropping off under high temperature, low heat capacity, and high efficiency of energy saving.
2. Dual-layer case structure, lower external temperature.
3. Microcomputer PID control module enables precise temperature control and constant temperature requirements.
4. Temperature contrOller is programmable with 2 groups/16 segments, and avaiable to set temperature curve.
5. over-temperature alarm: wheN temperature exceeds the limit value, machine will send out light-sound signal and stop heating.
Specifications:
| Chamber Size |
3000(W)*500(L)*200(H)mm Capacity: 30 liters |
| Max. Temperature |
1200c |
Continuous Operating
Max. Temperature |
1150c |
| Heating Rate | 0~30 c/min |
| Heating Element |
High temperature alloy |
| Temperature Control |
SCR controller and PID parameter self-setting |
| Display Accuracy | ±1 deg.C |
| Voltage |
AC 380V, 50/60Hz |
| Power |
10 kw |
| Thermocouple | S type |
Standard Accessory |
High temperature gloves 1 pair, crucible tong 1pc |
Optional components:
1. A large screen paperless recorder, to achieve real-time temperature curve recorded with a memory card of experimental data analysis and printing.
2. Installation of an air intake, which can feed into air and inert gas. An exhaust chimney connecting stainless steel bellows, so that the generate toxic gas emissions to a specified location.
