| Material: | Silicon |
|---|---|
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Features:
Transmission Range 1.2-15μm; 17…>500μm
Refractive Index 3.41776 when 10μm
Reflective Loss 46.1% when 10μm
Density 2.3291g/cm
Melting Point 1414℃
Molecular Weight 28.09
Thermal Conductivity 163.32 W/(m K) when 40℃
Specifics Heat 703.4J/(kg K)
Thermal Expansion 3.9ⅹ10 /℃ when 200-300 K<111>
Hardness (mohs) 1150(Mohs 7)
Young's Modulus 131GPa
Shear Modulus 79.9GPa
Bulk Modulus 102GPa
Rupture Modulus 125MPa
Dielectric Constant 13 when f=9.37GHz
Solubility Water insoluble
Crystal Structure Single crystal, synthetic
Cleavage Planes (111)
Specifications:
Standard Diameter from 10mm to 300mm
Standard Thickness from 1mm to 30mm
Applications:
Windows, lenses, band pass filter, thermography, ATR crystals, FIR optics, mirrors
