2500*1300mm UV Flatbed Printer with RICOH GEN5 heads heads for rigid flat material like glass,ceramics,PVC board,wood


1.Brief Introduction:



-We use Fuji motors imported from Japan for X axis,ensure the stability of movement.

-LED water cool systerm,make the wick more durable.

-perfectly controlled droplet at 7PL, making photographic image quality

- auto ink refill system

- Auto vacuum generated negative pressure system. Easy to load the light material.

- with advanced automatic height detector which can detect the material thickness and find a good height position for best quality printing

- the whole table is divided into 4 vacuum zones which can be controlled according the size of material. Cost-saving.

- drawer-type UV lamp cassette makes it easy to replace the UV lamp. We use German UV lamps.
- Double guide rails for carriage movement, ensuring stability.

- Equipment with Taiwanese HIWIN mute guide rail, low noise.

- we use the most stable aluminium alloy for the body of the machine.
- Print head is with built-in heater, which prolonged the life span



2.Techincal parameters:

Model	WT-2500UVF
Printhead	RICOH GEN5
Printhead Quantity	2/3/4/5/6/7/8PCS
Printhead Control	Software automatically adjusts the nozzle and voltage
Printhead height	1-100mm optional
Ink	Type	UV ink
	Color	CMYK+White,Varnish
	Cartridge capacity	1000ml
	Ink supply system	Automatic ink supply
Color Management	ICC or density curve
Print Media	All rigid flat media such as glass,aluminum panels, Acrylic,wood,wall panel,ceiling,organic board,ceramics, PVC board,corrugated board,foam board,metal plates, Plastic,brick,stone…
Drying System	2 UV lamps
Print Size	1300*2500mm
Print Speed	Outside light	17m2/h(low speed)
		29m2/h(medium speed)
		37m2/h(high speed)
	Inside light	9m2/h (low speed)
		16m2/h(medium speed)
		20m2/h (high speed)
Software	GMG
Operating System	Windows XP Windows 7
Platform Absorption	1500W Turbo fan
Data interface	USB2.0
Power supply	50/60Hz 220V(30%)>30A
File Format	BMP TIF JPG
Temperature	15-28℃
Humidity	40%-60%
Machine Size	L*W*H(4000*2000*1350mm)
