| Brand Name: | ADI |
|---|---|
| Size: | SOT23-5 |
| Type: | Precision Voltage Reference |
| Material: | N/A |
| Color: | N/A |
| Model Number: | ADR391AUJZ-REEL7 |
| Place of Origin: | United States |
| Package: | sot23-5 |
| Date Code: | 16+ |
Quick Details
Specifications
the following example is for you reference.
ADR391AUJZ ADI
(NEW and ORIGINAL)
(2.5V Micropower, Low Noise Precision Voltage Reference with Shutdown)
Features:
- Compact 5-Lead TSOT Package
- Low Temperature Coefficient:
B-Grade: 9 ppm/C
A-Grade: 25 ppm/C - Initial accuracy:
B grade: 4 mV maximum (ADR391)
A grade: 6 mV maximum - Ultralow output noise: 5 V p-p
(0.1 Hz to 10 Hz) - Low Dropout Performance: 300 mV
- Low supply current: 3 A Maximum in Shutdown 140 A Maximum in Operation
- No external capacitor required
- Output Current Capability: 5 mA
- Automotive grade available
- Wide Temperature Range: -40C to +125C
Technical details:
the ADR391/ADR392/ADR395 are precision 2.5 V, 4.096 V, and 5 V band gap voltage references, respectively, featuring low power and high precision in a tiny footprint. Using patented temperature drift curvature correction techniques from Analog Devices, Inc., the ADR39x references achieve a low 9 ppm/C of temperature drift in the TSOT package.
the ADR39x family of micropower, low dropout voltage references provides a stable output voltage from a minimum supply of 300 mV above the output. Their advanced design eliminates the need for external capacitors, which further reduces board space and system cost. The combination of low power operation, small size, and ease of use makes the ADR39x precision voltage references ideally suited for battery-operated applications.
Applications:
- Battery-powered instrumentation
- Portable medical instrumentation
- Data acquisition systems
- Industrial process controls
- Automotive
