LCD

Brand new original LCD screen

Screen Type

65 inch LCD

Ratio

16:09

Contrast Ratio

1400:1

Response Time

8ms

Physical resolution

1920x1080/60Hz

Display size

1435(H)×809 (V) (mm)

Color

16.7M

Brightness

400cd/m2

Panel Life

>60,000(hrs)

Viewing Angle

H170°/V160°

Touch Mode

Embedded infrared touch technology

Touch Point

Ten points

Touch resolution

4096 * 4096

Light-resistant

88K LUX working

Refresh Rate

172HZ

Response time

<5.81mS

Working current

255ma

Power

1.28W

Positioning accuracy

<1.5mm

the smallest touch diameter

≥5 mm

Write Method

Finger or Non-transparent material

Anti-knockingrating

Use tempered glass to provide knock rating, which is no scratch and high transparent toughened glass.750g steel ball falling from 1m height, the sample is not broken.

Transmittance

>98%,up to 100%(no glass)

Supply voltage

+5V DC allowable range +4.75V~+5.25V

Operating voltage

USB* 2, monitor switch, computer switch

Interface mode

USB2.0(slave)at full speed

System Campatibility

Windows7/Windows8/Windows10/Android 4.4X/XP

Measurement of drift

Drift does not change with the environment.

Service life

over 8 years

Number of touch

Unlimited

Repair rate

0.3 percent

CPU

Intel i3

Mainboard

Industrial personal computer mainboard

Hard disk

120GB SSD

RAM

Kingston 4GB

Graphics card

1G independent graphics cards

Audio card

Integrated 6.1 channels HD Realtek ALC622 audio card

Network card

100M Onboard NIC/WiFi wireless network card

Loudspeaker

2*10W

Compatible video format

PAL/NTSC

OS

Windows7/Windows8/Windows10/XP/Android4.4X

Enclosure Color

Black with silvery white edge

Installation Type

Wall-mounted

Input/Output Interface

AC power supply interface, headphone output, multimedia USB input - 1, HDML input - 2, PC - RGB input, AV input, AV output, PC - audio input, YPBPR (color) input, the RF - TV signal input, PC - USB 2.0 * 4 - USB 3.0 * 2, PC - HDML output interface, PC - cable front-end ports - 1, PC - WiFi antenna interface - 1, PC - VGA output, PC - DVI output, PC - PS/keyboard mouse

Operation system

TV, touch and display combined

G.W/N.W

91/78(KG)

External dimension

1546(W)x920(H)x125.9(D)mm

Size of packaging

1740(W)x1100(H)x250(D)mm

Power consumption

220W

<1W

Anti-explosion function

4MM Tempered Glass,anti-explosion,scratch-resistant

Shell material

Sheet metal spray paint

Physical design

Outside the borders there's no edges and corners and it's smooth. The built-in computer is integrated design and easy to maintain. The built-in touch screen, LCD screen and shell are formed into its own.

Features

the stability of the height will not drift because of time and environment change.
the High degree of adaptability will not be disturbed by the current,voltage and also by the static electricity,can be suitable for some harsh environmental conditions.
High light penetration without intermediate medium and the high pervious to light can up to 100%.
the good features touch is used without efforts which has no special requirements. No matter touch things are hard, conductive or not, do not affect the normal use.

Other capability

Infrared touch screen without drift (handwritten), support a variety of formats high-definition digital TV, bring their own picture in picture function. (TV can work independently, without start computer watch TV).

Ramdon accessory

Manual*1 (including the warranty card), certificate of approval*1, the power cord*1, WiFi receiver*1, Touch pan*1, remote control*1, key*2
