| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Weight: | 7000kgs |
| Power(W): | 30k |
| Voltage: | 380v |
| Model Number: | BDS180H |
| Brand Name: | FOREVER |
| Place of Origin: | China (Mainland) |
| Production Capacity: | 3~5sq.m./hr |
| Use: | Granite |
| Type: | Stone Cutting Machine |
| Condition: | New |
Quick Details
Specifications
the following example is for you reference.
1.Brief Introduction:
2.Techincal parameters:
Model
BDS180H
BDS220H Maximum use of the saw blade(mm)
1800
2200 Transverse effective stroke of saw blade(mm)
3100/3600
3600 Effective stroke of saw blade lift(mm)
900/1100
1100/1300 Working table area(mm)
1700*1700
1700*1700 Total power(Kw)
34.85
42.25 Mainly motor(Kw)
30
37 Lifting motor(Kw)
3.75
3.75 Feed motor(Kw)
1.5
1.5 Installation dimensions L*W*H(mm)
7300*5150*5210
7800*5150*6000 Mass(kgs)
7000
7500
3.Performance features:
