| Temperature range: | -200-1300 |
|---|---|
| Accuracy: | 0.2 |
| Theory: | Temperature Recorder |
| Usage: | Industrial |
| Model Number: | HPS3008 |
| Brand Name: | HELPASS |
| Place of Origin: | China (Mainland) |
| Product name: | HELPASS HPS3008 Multi-Channel Temperature Meter(8 channels) |
| Channels: | 8 |
| Graduation: | Thermocouple: K,T,B,E, J,N,R,S |
| Correction: | Error correct for each channel |
| Power supply: | 198 -242V(AC),47.5 -63Hz |
| Interface: | RS-232C/ U disk interface/ Relay switch output/GPIB(option) |
Quick Details
Specifications
HELPASS HPS3008 Multi-Channel Temperature Meter(8 channels)
Feature
Specification
Feature
? TFT color LCD display
? Innovative use of a key shuttle, easier to operate
? Compatible thermocouple, thermal resistance temperature sensor
? Each channel can be independently set temperature probe type
? Temperature compensation function
? Broken thermocouple check function? Innovative portable temperature probe insertion mode
Application
● Household appliance,Heating Appliance,Thermostat,oven,Thermal Protector
● Food,Pharmacy,Granary,Incubator,Storage Room
● Photoelectric, intelligent cooling, Lighting, motor, transformer, automobile manufacturing
Specification
Model |
HPS3008 |
HPS3016 |
HPS3024 |
HPS3032 | |||
Features | |||||||
Displayer |
TFT color liquid crystal display | ||||||
Display Language |
Optional operation interface in English and Chinese | ||||||
Measurement function | |||||||
Graduation |
Thermocouple:K,T,B,E, J,N,R,S/ Thermal Resistance:PT100,CU50 | ||||||
Basic Accuracy |
0.2°C | ||||||
MeasurementRange |
-200°C－1300°C(Variation depend on graduation) | ||||||
Resolution |
0.1°C | ||||||
Channels |
8 |
16 |
24 |
32(Extendable) | |||
Measurement Speed(time/sec) |
Slow:2 Medium:10 Fast:30 | ||||||
Correction Function |
Error correct for each channel | ||||||
Cold junction compensation |
Accuracy 0.5°C | ||||||
High-voltage protection |
Maximum 400V,AC/DClive lineMeasurement | ||||||
Others |
Broken thermocouple check function | ||||||
Test signal | |||||||
Thermocouple temperature probe | |||||||
K |
-50.0℃ －1200.0℃(Accessory) | ||||||
T |
-50.0℃ －400.0℃ | ||||||
B |
100.0℃ －1800.0℃ | ||||||
E |
-50.0℃ －800.0℃ | ||||||
J |
-50.0℃ －1000.0℃ | ||||||
N |
-50.0℃ －1200.0℃ | ||||||
R |
-50.0℃ －1700.0℃ | ||||||
S |
-50.0℃ －1700.0℃ | ||||||
Thermal resistance temperature probe | |||||||
PT100 |
-50.0℃ －400.0℃ | ||||||
Cu100 |
-50.0℃ －150.0℃ | ||||||
Cu50 |
-50.0℃ －150.0℃ | ||||||
Sorting and interfaces | |||||||
Comparator |
High/low beep Individual setting High/low value for each channel | ||||||
Interface |
RS-232C interface/U disk interface/Relay switch output/GPIB(Option) | ||||||
General Specification | |||||||
Working Environment |
0°C－40°C, ≤90%RH | ||||||
Power Supply |
198V－242V(AC),47.5Hz－63Hz | ||||||
Power Consumption |
≤30 VA | ||||||
Dimension |
270 mm(W) x 120 mm(H) x 335 mm(D) | ||||||
Weight |
2.5kg | ||||||
