| Type: | Vacuum Packing Machine |
|---|---|
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Certification: | ISO9001:2008 |
| Weight: | 1600 |
| Dimension(L*W*H): | 6525*1000*1700 |
| Model Number: | DZR420 |
| Brand Name: | Vapack |
| Place of Origin: | China (Mainland) |
| Power: | 50hz |
| Voltage: | 380v |
| Driven Type: | Electric |
| Automatic Grade: | Automatic |
| Packaging Material: | Plastic |
| Packaging Type: | Film |
| Application: | Apparel,Chemical,Food |
| Condition: | New |
Quick Details
Specifications
Model |
Bottom film width (mm) |
Top film width (mm) |
Vacuum degree |
Powder (V/HZ) |
Total dimension(mm) |
Total Power(KW) |
Total weight (kg) |
DZR420DJ,DH series |
423 |
393 |
≤200PA |
380;50 |
6525*1000*1700 |
10 |
1600 |
DZR520DH,T series |
523 |
493 |
≤200PA |
380;50 |
7585*1100*1700 |
13 |
2300 |
Remarks: Pls select the right product model according to your product or contact us for the further inquiry.
Product Characteristics
1.the vacuum chamber, working platform and machine frame of the vacuum packing machine are made of 3042B stainless steel plates which strictly meets GB9 77-2004 national Standard.
2. the vacuum chamber uses the silicone seal cushion to avoid the phenomenon of other vacuum packing machine suppliers` bad sealing effect.
3. the connecting rods of the aluminum and magnesium not only keep good looks and corrosion resistance but also prevent the deformation.
4. with the best of the domestic electric appliance control, electric system has a quite low failure rate.
5. the vacuum pump is made in the shanghai second vacuum pump factory, the best vacuum pumps supplier in CN(or use German import vacuum pumps).
