| Rated Current: | 4 |
|---|---|
| Rated Voltage: | 220 |
| Rated Power: | 80kw |
| Frequency: | 50 |
| Speed: | 1500 |
| Output Type: | AC Single Phase |
| Brand Name: | SKTM |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
| AVR | SX460 |
| Sensing voltage | Jumper selectable120(95-132)VAC, 240(190-264)VAC, single phase 2wire |
| Frenquency | 50-60Hz nominal |
| Voltage Input | Max 90VDC at 207VAC input |
| Resistance | 15 Ω minimum |
| Regulation | <±1% RMS with 4% engine governing |
| Voltage Build-up | Residual voltage at avr terminal >5vac |
| External Voltage Adjustment | :+/-7% with 1k ohm 1 watt trimmer |
| Generator Power | <150kw |
