P1.667  indoor HD LED display  P1.914 indoor HD LED display Full color P1.2 HD indoor LED video display

Arise Technology Co., Ltd



1, Black LED + Black mask, High contrast Rate, vivid effect

2, high end S-PWM driver IC, high Refresh rate, high grayscale, high brightness and without ghosting image

3, high brightness for each single Pixel, color correction, bettercolor consistency

4, Kit of brushed aluminum alloy,  beautiful and fashionable form, no fan Design, ensure a silent operation

5, Convenient & Fast installation, Easy maintenance

Product model	P1.667	P1.914	P2.0	P2.5
Pixel pitch	1.667mm	1.914mm	2.0mm	2.5mm
Pixel density	360000pixel/㎡	272936pixel/㎡	250000 pixel/㎡	160000 pixel/㎡
LED LAMP Pixel Configuration	SMD 3 in 1	SMD 3 in 1	SMD 3 in 1	SMD 3 in 1
Brightness	1000 nit	1000nit	1000nit	1000nit
Horizontal viewing angle	120°
Vertical viewing angle	120°
MTBF	10000 h
Lifespan	100000 h
Flatness	≤0.1mm/M2
Storage temperature	-40℃～85℃
Operation temperature	－20～50℃
Work environment humidity	10%～90％
Input voltage	AC90－240V
Module voltage	DC5V
AVE.Consumption	35W/cabinet	75W/cabinet	29W/cabinet	29W/cabinet
Max. Consumption	150W/cabinet	300W/cabinet	120W/cabinet	95W/cabinet
Driver Mode	1/30	1/30	1/30	1/30
Refresh rate	2000 Hz	2000Hz	2000Hz	2000Hz
Frame rate	60 Hz	60 Hz	60 Hz	60 Hz
Grey scale	16 bit	16 bit	16 bit	16 bit
Color	281 T	281 T	281 T	281 T
Color temperture	6500K	6500K	6500K	6500K
Contrast ratio	4000:1	4000:1	4000:1	4000:1
Cabinet size(L*H*D)	400*300*66	612.5*344.5*66	400*300*66	400*300*66
Cabinet weight	4.6 Kg	8.1 Kg	4.6 Kg	4.6 Kg
Cabinet resolution(L*H)	240*180  Dot	320*180 Dot	200*150  Dot	160*120  Dot
Cabinet material	Die-cast Aluminum	Die-cast Aluminum	Die-cast Aluminum	Die-cast Aluminum
Ingress protection	Indoor IP43	IndoorIP43	IndoorIP43	IndoorIP43
Moudle size(L*H)	200*300 mm	306.25*172.25 mm	200*300 mm	200*300 mm
