Application
VCF Cooking oil recycling machine can save you up to 50% on your oil Purchasing, reduce your storage needs, reduce your oil disposal needs, increase the taste and quality of your foods and provide your customers healthier deep Fried foods.

however you decide to dispose of your cooking oil, don't dump it down the sink Drain or flush it down the toilet because it can clog pipes and eventually even Pollute local waterways.



Our VCF cooking oil recycling Machine can greatly increase the usable life of your cooking oil by removing Water, impurities, odor, acidity, color etc, instead of simply replacing the Oil. this machine will give you more use out of your restaurant's cooking oil. It Is safer for employees, it lasts longer, and it removes the unsightly waste that normally comes with frying oil.

Specifications

Model		VCF-10	VCF-20	VCF-30	VCF-50	VCF-100	VCF-150	VCF-200	VCF-300
Capacity(L/min)		10	20	30	50	100	150	200	300
Working vacuum		-0.06～-0.095 Mpa
Working pressure		≤ 0.4 Mpa
Temperature range		20-80℃
Water content		≤20 ppm
Gas content		≤ 0.1%
Acid Value		≤0.05 mKOH/g
Cleanness		NAS 6 grade
Filtering precision		≤1 micron
Continuous work		100 hr
No failure running		≥5000 hr
Power supply		380V, 50HZ, 3PH ( or Customized )
Working noise		65 dB
Heating power (kw)		24	24	30	40	60	90	145	160
Total power (kw)		27	27	33.5	44	65	97	157	178
Inlet/outlet(mm)		25	25	32	32	48	50	58	65
Weight (kg)		300	350	400	500	800	1000	1200	1350
Dimension (mm)	L	1100	1230	1250	1500	1650	1750	1900	2000
	W	800	810	850	950	1000	1200	1250	1350
	H	1250	1260	1300	1400	1600	1750	1950	2100
