the following example is for you reference.


1.Brief Introduction:





2.Techincal parameters:

Item		Unit	HS-CXJ-1200	HS-CXJ-1400	HS-CXJ-1750	HS-CXJ-1800
Outline of mould		MM	1200X1000	1430X1230	1750X1500	1830X1630
Max. Product size		MM	1030X830X       400	1260X1060X       400	1580X1330X       400	1660X1460X       400
Size for filling guns		MM	1050X850	1280X1080	1600X1350	1680X1480
Steam	Pipe inlet	MM	DN80	DN80	DN100	DN100
	Mould inlet	MM	DN40	DN40	DN40	DN40
	Pressure	Kg/cm2	3～6	3～6	3～6	3～6
	Consumption	Kg/cycle	2～3.5	2～3.0	2～3.5	2～3.5
Cooling water	Pipe inlet	MM	DN65	DN65	DN80	DN80
	Mould inlet	MM	DN25	DN25	DN25	DN25
	Pressure	Kg/cm2	3～4	3～4	3～4	3～4
	Consumption	Kg/cycle	15～30	15～30	15～30	15～30
	Temperature	℃	40～50	40～50	40～50	40～50
Compressed air	Pipe inlet	MM	DN65	DN65	DN80	DN80
	Pressure	Kg/cm2	4～5	4～5	4～5	4～5
	Consumption	M3/cycle	0.015~0.02	0.015~0.02	0.015~0.02	0.015~0.02
Vacuum system	Pipe inlet	MM	DN25	DN25	DN25	DN25
	Pressure	Kg/cm2	1.5～3	1.5～3	1.5～3	1.5～3
	Consumption	Kg/cycle	10～20	10～20	10～30	10～30
	Temperature	℃	25～35	25～35	25～35	25～35
Cycle time		S/cycle	38～55	38～60	38～80	38～80
Drain pipe		MM	DN100	DN150	DN150	DN150
Installation power		KW	12.5	12.5	16.5	16.5
Overall size		M	5X2.1X3.27	5X2.33X3.5	5.2X2.65X3.8	5.2X2.72X4
Machine weight		KG	≈4500	≈6000	≈8000	≈8600





3.Performance features:

●Foam products have low moisture content. Low energy consumption and short production cycle time. Perfect stabilization of size;.

●Interchangeable various types of moulds, equipment compatibility, saving mould cost;

●the frame is welded by quality steel, high strength and good stability;

●High temperature heat treatment after welding Using imported CNC machining center. the underlying fine uses sand-blasting, galvanizing and the overall surface painted, high corrosion resistance;

●Using advanced multi-cylinder hydraulic clamping systems, high clamping speed and locking strength;

●Using advanced piping system, for good steam pressure balance and stability;.

●Efficient vacuum cooling system, independent of the drainage system, greatly reducing vacuum time;

●Pressure feed, advanced sensors to control the feeding amount and density;

●Automatic computer control system, color touch-screen control, easy to operate;
