the following example is for you reference.


1.Brief Introduction:





2.Techincal parameters:

Subjects			Unit	HS-FB-2000	HS-FB-3000	HS-FB-4000	HS-FB-6000
Mould size			mm	2030×1020×620	3050×1020×620	4060×1240×640	6090×1240×640
product size			mm	2000×1000×600	3000×1000×600	4000×1200×600	6000×1200×600
Steam	Inlet size		mm	Φ125	Φ125	Φ150	Φ150
	Consumption		Kg/cycle	20～30	30～40	45～55	55～65
	Pressure		Mpa	0.6～0.8	0.6～0.8	0.6～0.8	0.6～0.8
Compressed air	Inlet size		mm	Φ65	Φ65	Φ80	Φ80
	Consumption		M3/cycle	1~1.5	1.5~1.8	2.0~2.2	2.2~2.5
	Pressure		Mpa	0.6～0.8	0.6～0.8	0.6～0.8	0.6～0.8
Material      filling	Number of Injectors		PC	4	8	10	12
	Injector size		mm	70	70	70	70
Drain outlet			mm	Φ125	Φ125	Φ150	Φ150
Main drain pipe			mm	Φ150	Φ120	Φ200	Φ200
Blower motor			Kw	4	4	7.5	7.5
Blower outlet			mm	Φ150	Φ150	Φ200	Φ200
Hydraulic motor			KW	5.5	5.5	5.5	5.5
Installation power			KW	9.5	9.5	13	13
Cycle time		15g/l	Min/cycle	6	7	9	10
Overall dimension (L×W×H)			mm	4700×2260× 2200	5700×2260× 2200	6700×2480× 2450	8700×2480× 2450
Weight			T	4.5	6.2	7	8.5





3.Performance features:
●the machine adopts opening and closing mould, locking mould of the hydraulic system with stable running.
●Steam general valve uses steam ball valve with good airproof characteristics and long life.
●Four safe fixing: safe and interlock switch, pause switch, urgent stopping switch, safe valve
●Touch screen display, graphical interfaces, Chinese and English display, soft button etc
●Refrigerating constrainedly, high cooling efficiency, low water convenient filling material, high effectiveness
●Feeding material automatically, convenient filing, high efficiency
●the main components such as CPU, touch screen are from the well-known company with stable quality
●Block conveying line and electronic weighing scale for machine is optional.
