| Brand |
EcooSetter |
| Model |
T-400X(XA) |
T-400F(FA) |
T-400S(SA) |
T-400E |
| Laser wavelength |
830nm |
| Imaging System |
64 |
48 |
32 |
24 |
| (channel) |
| Throughput |
34 |
28 |
22 |
16 |
| 800mmx660mm 2400dpi |
| (plates/hour) |
51 |
44 |
36 |
28 |
| 800mmx660mm 1200 dpi |
| Plate Size |
Max.800mmx660mm, Min.254mmx250mm |
| Plate Type |
830nm thermal plate |
| Plate Thickness |
0.15mm to 0.30mm |
| Resolutions |
2400 dpi |
| Repeatability |
±5μm (Continuous exposing for four times or |
|
|
|
| above on the same plate with a |
| Temperature of 23 ℃ and humidity of 60%) |
|
|
|
| Weight |
800/TBA KG |
| Size(WxDxH) |
1900mmx1200mmx1000mm (WxDxH) |
| TBA |
| Power Supply |
Single-phase: 220AC,+6%,-10%,4KW |
|
|
|
| Environment |
Recommended: 21-25℃, Allowed temperature: |
| 18-26℃, humidity: 40-70% |
|
|
|
