Technical Parameter >>
Power supply |
Made to order |
Motor power |
3KW |
Motor rotary speed |
2840r/min |
Operation air pressure |
0.5~0.8Mpa |
Air consumption |
80L/min |
Auto-feeding length |
3~200mm |
Cutting length |
Non limited when manual cutting |
Cutting width |
MAX. 125mm |
Cutting height |
MAX.140 mm |
Feeding speed |
Stepless timing 0~3m/min |
Saw blade specification |
Φ500mm×4.4mm×φ30mm Z=120 |
Cutting height |
140 mm |
Dimension |
5530mm×1770mm×1840mm |
Weight |
800kg |
1.Each product will be carefully packed with plastic film package,to make sure it will arrive safely and available for customized packing.
2.for wooden case, the machine is packed by plastic film first, then packed in wooden case carefully.
