| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Certification: | SGS |
| Weight: | 1980KG |
| Dimension(L*W*H): | 960mm*1560mm |
| Power(W): | 25KW |
| Voltage: | 380V/3P/50HZ |
| Model Number: | PFB-80 |
| Brand Name: | SUNKOO PTFE Teflon extruder operator |
| Place of Origin: | China (Mainland) |
| Automatic Grade: | Semi-automatic |
| Screw Design: | Single-screw |
| Application: | Bar |
| Condition: | New |
| Plastic Processed: | PTFE/Teflon/plastic |
| Product Type: | PTFE rod/bar |
| Usage: | PTFE teflon rod extruder operator machine |
| Warranty: | 1 Year |
| Mould: | Customized |
| Raw material: | PTFE powder |
Quick Details
Specifications
I.Features of PTFE Teflon RAM plastic extruder machine
- Produce PTFE/Teflon rod dia from 20mm to 80mm.
- Honrizontal Extruder.
- RAM extruding machine.
- Using for Pre-sintering PTFE material.
- Suit for new PTFE material or Recycle PTFE material.
II. Advantages of our PTFE Teflon RAM plastic extruder machine
1, Automatic control
2, Easy operation
3, Low power consumption
4, Product size stability
5, Precise sintering
6, Environment-friendly and Energy-saving
III. Technical Specification:
| PTFE EXTRUDER | PTFE rod plastic extruder machine Dia 20mm-80mm |
| Serial/Model NO. | PFB-80 |
| Type | PTFE Horizontal Type RAM Extruder |
| Screw | Single-Plunger |
| Rod Dia Range Min - Max Dia | 25-80 mm |
| Automatic | Automatic |
| Computerized | Computerized |
| Plastic Processed | Sintered PTFE Powder |
| Machine with PTFE Rod Mould | Mould Depends on Required |
| Process | RAM Extrucer M/c |
| Power KW (Main Motor+ heating) | 24 |
| Tolerance mm | 0.5-2mm + |
| Length mm | Unlimited |
| Production Per Hour in Kg | 7-10+ |
| Temperature zone | 4-8 |
| Compressive force [kN] | 100 -500 |
| Electricity Consumption Per hour | 2.5 |
| Weight of the Machine | 960 |
| High of the Machine mm | 1560 |
| Voltage/PH/Hz | AC380V 50Hz 3 Phase |
| Floor area of the Machine M2 | 1.2 |
