Technical specification

input

Voltage

190-264V AC

Frequency

50-60 Hz nominal

phase

1

wire

2

Output

Voltage

Max 90V DC at 207V AC input

Current

Continuous 4 A DC

Intermittent 6A for 10 secs

Resistance

15 ohms minimum

Regulation

+/- 1.0% (see note 1)

Thermal drift

0.04% per deg. C change in AVR ambient (note 2)

Typical system response

AVR response

20 ms

Filed current to 90%

80 ms

Machine volts to 97%

300ms

External voltage adjustment

+/- 10% with 1 k ohm 1 watt trimmer(see note 3)

under frequency protection

Set point

95% Hz(see note 4)

slope

170% down to 30 Hz

Unit power dissipation

12 watts maximum

Build up voltage

4 volts @ AVR terminals
