400kw Cummins Generator Open Type 500kVA Cummins Diesel Generator 50Hz
STANDARD CONFIGURATION
*Industrial Cummins water-cooled diesel engine
*Single bearing alternator with insulation class H and IP23
*circuit breaker
*Steel base fuel tank with anti-vibration mounting
*9 dB muffler exhaust system, free-maintenance battery, user's manual
*Flexible fuel lines and lube oil drain cock
*Deepsea controller module
*Shrink wrap packing method

Genset Model	GPC500(S)
Prime power (50Hz)	400KW/500KVA
Standby power (50Hz)	440KW/550KVA
Frequency/Speed	50Hz/1500rpm
Voltage	220V/380V
Phase	Three phase, four wires
Manufacturer	GENLITEC POWER
Engine model	Cummins KTA19-G4
Alternator model	Stamford HCI544C
Controller model	Deepsea DSE7320



ENGINE DATA
Manufacture	Cummins Engine Company Ltd.
Model	KTA19-G4
Engine speed	1500rpm
Engine power (Net)	507KW/680HP
Engine power (Gross)	563KW/755HP
Number of cylinders	6
Cylinder arrangement	Vertical in-line
Cycle	4-stroke
Aspiration	Turbocharged, Aftercooled
Combustion system	Direct injection
Compression ratio	13.9:1
Bore and Stroke	159 x 159mm
Displacement	18.9 liters
Fuel system	PB pump_GAC governor /BYC
Cooling system	Water cooled
Speed-droop	5%
Starting system	DC24V



FUEL CONSUMPTION
Engine speed	Fuel consumption
	G/kw.H	L/H
Standby power	206	136
Prime power	205	122
75% of prime power	210	94
50% of prime power	218	65



ALTERNATOR DATA
Manufacture	STAMFORD Co., Ltd.
Model	HCI544C
Output power	400KW/500KVA
Number of phase	3
Power factor (Cos Phi)	0.8
Altitude	≤1000m
over speed	2250RPM
Number of pole	4
Exciter type	Shunt
Insulation class	H
Voltage regulation	±0.5%
Sustained short circuit current	300% (3 in): 10s
Total harmonics (TGH/THC)	<4%
Wave form: NEMA = TIF	<50
Wave form: I.E.C = THF	<2%
Bearing	Single
Coupling	Direct

50Hz
3 phase, 4 wires, 0.8PF, 1500rpm, 415-230V/240-115V

Gen-set Model	POWER				Engine Model	Open Frame Dimension
	Prime Power		Standby Power		CUMMINS
	KW	KVA	KW	KVA		Dimension(LxWxH)mm	Weight(kg)
GPC25	20	25	22	27	4B3.9-G	1750x700x1100	830
GPC38	30	38	33	42	4BTA3.9-G	1750x700x1100	850
GPC63	50	63	55	70	4BTA3.9-G2	2060x700x1100	890
GPC94	75	94	83	104	6BT5.9-G	2120x830X1260	1250
GPC125	100	125	110	138	6BT5.9-G2	2320x810x1320	1440
GPC150	120	150	132	165	6BTAA5.9-G2	2320x810x1320	1440
GPC188	150	188	165	207	6CTA8.3-G2	2800x850X1290	1750
GPC200	160	200	176	220	6CTA8.3-G2	2900x850x1290	1860
GPC250	200	250	220	275	6LTAA8.9-G2	2900x950x1630	2200
GPC450	360	450	396	495	QSZ13-G2	3500x1400x1800	3050
GPC500	400	500	440	550	QSZ13-G3	3500x1400x1800	3150
GPC250	200	250	220	275	NT855-GA	3000x970x1460	2450
GPC275	220	275	242	303	NT855-G1A	3100x970x1460	2900
GPC313	250	313	275	345	NT855-G1B	3100x970x1460	2900
GPC344	275	344	303	379	NT855-G2A	3150x970x1460	3300
GPC350	280	350	308	385	NT855-G4	3250x970x1460	3350
GPC375	300	375	330	413	NTA855-G7	3250x1370x1500	3400
GPC400	320	400	352	440	NTA855-G7A	3250x1370x1500	3450
GPC450	360	450	396	495	KTA-G3	3400x1250x1800	4350
GPC500	400	500	440	550	KTA-G4	3400x1250x1800	4800
GPC560	450	563	495	620	KTAA19-G5	3650x1780x1950	4950
GPC625	500	625	550	688	KTAA19-G6A	3650x1900x2250	5000
GPC650	520	650	572	715	QSKTAA19-G3	3700x1900x2250	5000
GPC750	600	750	660	825	KTA38-G2	4350x1630x2250	7900
GPC800	640	800	704	880	KTA38-G2B	4350x1630x2250	7900
GPC900	720	900	792	990	KTA38-G2A	4350x1630x2250	7900
GPC1000	800	1000	880	1100	KTA38-G5	4380x1890x2320	8220
GPC1125	900	1125	990	1238	KTA38-G9	4570x2010x2320	8900
GPC1250	1000	1250	1100	1375	KTA38-G9	4570x2010x2320	8900
GPC1250	1000	1250	1100	1375	KTA50-G3	5200x2100x2600	10300
GPC1500	1200	1500	1320	1650	KTA50-G8	5800x2100x2760	10600

60Hz
3 phases, 4 wires, 0.8PF,1800 rpm,440-240V/254-120V

Gen-set Model	POWER				Engine Model	Open Frame Dimension
	Prime Power		Standby Power		CUMMINS
	KW	KVA	KW	KVA		Dimension(LxWxH)mm	Weight(kg)
GPC30	24	30	27	33	4B3.9-G	1750x700x1100	830
GPC43	34	43	38	48	4BT3.9-G	1750x700x1100	850
GPC63	50	63	55	70	4BT3.9-G2	2060x700x1100	890
GPC113	90	113	99	125	6BTA5.9-G	2120x830x1260	1250
GPC125	100	125	110	138	6BTA5.9-G2	2320x810x1320	1440
GPC150	120	150	132	165	6BTAA5.9-G2	2320x810x1320	1440
GPC188	150	188	165	207	6CTA8.3-G2	2800x850x1290	1750
GPC200	160	200	176	220	6CTAA8.3-G2	2900x850x1290	1860
GPC250	200	250	220	275	6LTAA8.9-G2	2900X950X1630	2200
GPC450	360	450	396	495	QSZ13-G2	3500x1400x1800	3050
GPC500	400	500	440	550	QSZ13-G4	3500x1400x1800	3150
GPC250	200	250	220	275	NTT855-GA	3000x970x1460	2450
GPC313	250	313	275	345	NTT855-G1	3100x970x1460	2900
GPC344	275	344	303	379	NTT855-G1B	3150x970x1460	3300
GPC400	320	400	352	440	NTT855-G3	3250x970x1460	3350
GPC450	360	450	396	495	KTA19-G2	3400x1250x1800	4350
GPC500	400	500	440	550	KTA19-G3	3400x1250x1800	4350
GPC563	450	563	495	620	KTA19-G4	3400x1250x1800	4800
GPC588	470	588	517	647	KTAA19-G5	3650x1780x1950	4950
GPC675	540	675	594	743	KTAA19-G6A	3650x1900x2250	5000
GPC775	620	775	682	853	KTA38-G	4350x1630x2250	7900
GPC900	720	900	792	990	KTA38-G2	4350x1630x2250	7900
GPC1000	800	1000	880	1100	KTA38-G2A	4350x1630x2250	7900
GPC1250	900	1125	990	1238	KTA38-G4	4380x1890x2230	8220

*please seeking for more engine models.
*alternator option: KWEIS series brushless synchronous AC alternator;Stamford; Leory Somer etc.
