Basic parameters
Size: 380 mm * 210 mm * 83 mm
Weight: about 2.5 kg
Working voltage: AC220V 50 Hz
Output voltage: DC24V (over-current protection function)
the number of channels: 1 or 2 road
Display mode: direct display
Signal input: 4-20 mA

Control Output: AC 250V 10A, DC 30V 10A (relay switch output)
Connection mode:

Two wire, Three wire system 4-20 mA current signal of the transmitter
or four wire bus transmitter
Response time: ≤ 8s

Measurement Range:0~9999(can be set)

Alarm:More Than 90dB alarm way

Output Control: 1-2 road alarm control relay output
Temperature range: - 10 ℃ ~ 50 ℃
Humidity:15% ~ 70% RH (No condensation)

Installation Method: wall-mounted installation
