Basic parameters
Size: 480 mm * 250 mm * 130 mm
Weight: about 6 kg
Working voltage: AC220V 50 Hz
Output voltage: DC24V
Channel number: 4, 6, 8

Display Mode: multiplex highlight digital tube display directly
Signal input: 1-8 standard 4-20 mA current loop road input,

Support two Wire and three-wire system all sorts of transmitter

Response Time:
Signal output: (optional) 1-8 standard 4-20 mA current loop output,

          and with input signal one to one

Communication Interface:
(optional) 1 road RS232 and RS485 digital bus interface,
Standard ModBus RTU protocol or non-standard,

Can connect the computer monitor

Sampling Accuracy: 12 bit AD
Measurement range: 0-9999 (can be set )
More than 90 dB alarm way: level alarm, secondary alarm more than 120 dB
Temperature range: - 10 ℃ ~ 50 ℃
Humidity: 15% ~ 70% RH (No condensation)

Installation Method: wall-mounted installation
