ZERO DROP TESTER

GENERAL INTRODUCTION---ZERO DROP TESTER

the Compact Drop Tester aims to verify packing drop-impact resistance performance in transport, handling and to determine the
Rationality of packing design as well as package impact-resistance grade, mainly applied for large-size package drop test objective.

Working Principle --ZERO DROP TESTER

the Compact Drop Tester consists of main working mechanism that includes testing specimen holder in a shape of E move down
in a rapid speed, which requests the testing specimen is placed on a platform by face, angle, corner.

the testing specimen move down quickly and away from testing specimen during test process, the E-shape holder fall into bottom
Plate through a buffer before testing specimen fall onto bottom plate.

FUNCTIONAL FEATURES--ZERO DROP TESTER

Rolling wheel Dual-Guide Structure design aims to avoid derailment in elevation & free drop and guarantees safety in test;

Employs motorized elevation design with less troubleshooting and easy to maintenance & repair;

DC Electromagnetic Chuck attracts drop holder (testing specimen) is available to release dropping holder instantaneously and ensures
the packing specimen can perform free drop and impact base vertically;

Using DC uninterrupted power supply to supply electromagnetic chuck in case of hurt or damage because of sudden power-off;
Inverted trapezoid structure design to guarantee no impact on bottom base in case of sudden drop of elevating mechanism;

It is designed with optical coder to collect height variant data & parameters of elevation simultaneously, which can display or set
Current height, target height as well as automatic shutdown when pre-settting height reached with its resolution can reach up to
1mm;

this drop test, is applied for large-size or medium-size package in dropping test, easy to testing specimen loading and unloading,
Available to implement drop test from corner, face, angle and the drop height can be set to start from zero;

Dual Hydraulic Buffer is designed to absorb instaneous impact energy from drop holder in case of secondary impact that will
Causes bad effect or rigid impact damage of drop holder;

TECHNICAL PARAMETERS--ZERO DROP TESTER

Model	LT-F-015S		LT-F-020S
Drop Height	0~1500mm(controllable)		0~2000mm(controllable )
Overall Dimension	W1500 X D1500 X H2500mm		W1500 X D1500 X H2900mm
Gross Weight	Approx.1500kg		Approx. 2000kg
Max. Specimen Weight	100kg, 100kg,200kg,300kg able to customize. Optional
Max. Specimen size (mm)	W1000 X D1000 X H800mm or customize
Display Method	LED digital display,controllable
Testing Method	Face, Edge, Corner full range drop
Drop Plate Material	Steel plate for standard
Drop Method	Electromagnetic and pneumatic combined
Accelerator	Pneumatic
Power Source	AC380V 50HZ
