| Place of Origin: | China (Mainland) |
|---|---|
| Chipset: | TSUMV56RUU-Z1 |
| Model: | VS.T56U21.21B |
| SINGLE/DUAL LVDS: | SUPPORT |
| SCREEN SIZE: | 21.5-27inch |
| Board Type: | LCD Analog TV |
| Resolution: | Max support 1920x1080 |
| Loudspeaker: | 3w*2 |
Quick Details
Specifications
LED& LCD TV mainboard board for EDP Panel with BT function
We supply high quality LED TV board video board. We devoted ourselves LED TV Solution more than 10 years. All products suitable for Asia market, Southeast market, and Mideast market, we are looking forwarder to become your long term partner in China.
Features:
CHIPSET TSUMV56RUU-Z1 BOARD TYPE LED TV Board PANEL Panel Type TFT LCD with LED Backlight Max Resolution up to 1920x1080@60Hz Interface Dual/Single LVDS ATV in Reception Range 48.25MHz—863.25MHz Input Impedance 75Ω Video System PAL,SECAM Sound System BG,DK,I Max Storage Channels 200CH VIDEO INPUT VGA Format up to 1920*1080@60Hz Interface D-SUB15 HDMI 480i,480p,576i,576p,720p,1080i,1080p HDCP Ver 1.2 CVBS Video System PAL,NTSC Video Level 1.0 Vp-p±10% AUDIO INPUT PC Audio L/R Audio Input CVBS L/R RCA Input AUDIO OUTPUT Max Output Power 2*1.6W(8Ω)THD+N＜10% Panel Voltage 3.3V/5V/12V POWER DC Input DC 12V Standby Consumption < 0.3W Backlight Adjust Type DC adjust OSD LANGUAGE Chinese, English, etc. KEY FUNCTION SOURCE, up, DOWN, RIGHT, LEFT, MENU, POWER
Technical details:
Our Workshop showing
Package:
Welcome to buy the low price 15.6 LED TV board support edp panel and blute tooth function for india market
Made in China from VIDEOSCAPE.
We are one of the leading manufacturers and suppliers in China, with many products in stock. Now, check the quotation with us
