Main Technical Data:
1. High chamber temperature range: -60 ~ +200℃
2. Low chamber temperature range: 0℃ ~ -70℃
3. the temperature shock range: -55 ~ +150℃
4. Low temperature chamber cooling time: from +25℃ to -70℃ time ≤ 70min;
5. High temperature chamber heating time: from +60℃ to +150℃ time ≤ 30min
6. Temperature deviation: ≤ ±2℃ (constant state)
7. Temperature fluctuation: ≤ ± 0.5℃ (constant state)
8. Temperature uniformity: ≤ 2 ℃ (constant state)
9. Shock test chamber temperature recovery time: ≤ 5min (100℃ ~ -55℃, with load 100KG aluminum)
10. Effective size inside the chamber: 2.01 cubic meter
11. Pneumatic damper switch mode
12. Refrigeration system: mechanical cascaded refrigeration / water cooling
13. Refrigerant: R404A/R23, in line with the requirements of the International Environmental Protection Convention
14. Wiring holes: 1) aperture Φ100mm, 4pcs, with a threaded cap and soft plug
15. Noise level: ≤ 75db (A)
16. Defrosting is not interrupted during the test, or defrost cycle 200 cycle
17. Total power consumption: 131kw

Specification:
Dimension: 1000 x 1000 x 1000 mm
Reference power: 380v/32.5
P.S Customization is provided, for more details kindly feel free to get in touch with us.
