| Type: | Other |
|---|---|
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Certification: | ISO |
| Dimension(L*W*H): | 3400*800*1450 |
| Weight: | 1400kg |
| Model Number: | YY1202 |
| Brand Name: | Yayi machinery |
| Place of Origin: | China (Mainland) |
| Power: | 5.5KW |
| Voltage: | Alternating Current 380V 50HZ, three phases and five lines |
| Driven Type: | Electric |
| Automatic Grade: | Automatic |
| Packaging Material: | Wood |
| Packaging Type: | |
| Application: | Apparel,Beverage,Chemical,Commodity,Food,Machinery & Hardware,Medical,Textiles |
| Condition: | New |
| Product name: | Double stell strip machine |
| Application: | Nailless plywood boxes, Wooden box |
| Raw material: | Galvanized steel |
Quick Details
Specifications
the following example is for you reference.
1.Brief Introduction:
Steel strip machine is popular used in Fold-able /collapsible/Nail-less plywood boxes,
Steel strip edges provides extra reinforcement to plywood and act as strong Hinges.
these boxes are very easy and quick to assemble and dissemble, thus Saving lot of cost in terms of shipping a
2.Techincal parameters:
|
Basic parameter |
Name |
YAYI professional Double steel strip machine |
|
Power |
Max Input power |
5.5kw |
|
Teeth mold length |
Plywood thickness |
10mm or 12mm for choice |
|
Raw material |
Steel strip SGCC |
85*0.7mm |
|
Productivity |
Speed |
8-10m/min |
|
Control system |
PLC |
Siemens PLC S7-200 224 module +223 expansion.
|
|
Electrical system |
Electrical parts |
Brand, Schneider-electric |
|
Dynamical System |
Servo-motor |
Brand, TaiwanKenty 2.0 kw |
|
|
Reducer |
Brand,TaiwanKimpo |
|
Hydraulic system |
Hydraulic parts |
Brand, JapanYuken |
|
Forming wheel |
- |
10 sets |
|
Feeder |
Automatic Rack |
Automatic rack MT-250 |
|
Gross weight / kg |
|
1400 |
|
Gross volume (L*W*H)/mm |
3400*800*1450 |
|
3.Performance features:
