Features:

Hidden display screen

128 channels

VOX function

TOT function

Battery indicator

Low power alerts

High voltage protection

Channel scan function

QT/DQT setting

Busy Channel  Lockout

Battery power saving settings

Wide/narrow band selective

Squelch Level Setting

Keypad Lock function

Low Power Alerts

Monitor function

Weight:133g (not contain antenna&belt clip)

Size:90mm*61mm*30mm (not contain antenna&belt clip)





Technical details:

Frequency range:136~174MHz 400~480MHz

Channel storage:128 channel

Working voltage:4.2V DC(not exceed 4.5V)

Antenna impedence: 50?

Frequency stability:±2.5ppm

Working temperature: -10℃ -  +40℃

Working current:emission status≤ 1.3A;  low power:0.6A

Reception status: ≤ 0.4A

Working mode:Same frequency simplex,different frequency simplex

Battery capacity:1500mAh

Transmitting power:high power: 2W  ±0.2W

low power: 0.5W ±0.1W

Modulation mode: F3E(FM)

Maximum frequency deviation: : ≤ 5KHz(25KHz) ; ≤ 2.5KHz(12.5KHz)

Stray power: ≤ 7.5uW

Adjacent channel power: :  ≤ -70dB(25KHz) ;  ≤ -65dB(12.5KHz)

Acceptance sensitivity: (12dB SINAD):  0.2uV @25KHz  ;0.25uV@12.5KHz

Audio output power: ≤ 1W

Audio distortion: ≤ 10％





More detail.

Package & shipping
by carton/OEM or ODM the package(MOQ should be not less than 300PCS)
Support DHL/EXPRESS/Fedex(tell us the ways you wanna deliver.


for learn more, contact our seller freely.
