1.Brief Introduction:

 Marine Valve V-Goal Marine Valve - Cast Iron Gate Valve 16K 50A JIS F7369

body	fc200
Bonnet	fc200
plate	fc200
Stem	C37710bd or be/sus420
disc	Bc6/sus420
Gasket	Non-asbestos



2.Techincal parameters:

DN	d	L	D	C	NO.	h	t	H	D2
50	50	200	155	120	8	19	20	300	140
65	65	220	175	140	8	19	22	350	160
80	80	230	200	160	8	23	24	400	180
100	100	250	225	185	8	23	26	450	200
125	125	270	270	225	8	25	26	520	224
150	150	290	305	260	12	25	28	580	250
200	200	320	350	305	12	25	30	700	315





3.Performance features:

Marine Valve V-Goal Marine Valve - Cast Iron Gate Valve 16K 50A JIS F-7369

Marine cast iron gate valve used in shipbuilding.

Applicable Scope:
the products are used for controling the medium to open and close, preventing Refluence in fuel/oil piping, lubricating oil piping, water piping and steam Piping at temperatures 120C Or less.
Dimensions of flange are according to JIS B2220 flange dimensions of steel Pipe.

Type: JIS F7363/7364/7369 5K/10K/16K

5K type:
Size: DN50-DN450
Normial Pressure: 5K
Seal Pressure: 0.76Mpa
Intensity Pressure: 1.03Mpa

10K type:
Size: DN50-DN450
Normial Pressure: 10K
Seal Pressure: 1.52Mpa
Intensity Pressure: 2.06Mpa

16K type:
Size: DN65-DN400
Normial Pressure: 16K
Seal Pressure: 1.73Mpa
Intensity Pressure: 2.36Mpa

Part Name Material
Body, Bonnet: Cast Iron, DI
Disc, Seat: Cast bronze Stainless Steel
Stem: Bronze Stainless Steel
Packing Flexible Graphite
