CHIPSET

TSUMP58CDT9-14

BOARD TYPE

LCD Monitor Main Board

PANEL

Panel Type

LCD TFT

Max Resolution

up to 1920x1200

Interface

Dual/Single LVDS

VIDEO INPUT

DVI

up to 1920*1200 @60Hz

HDMI

480I, 480P, 576I, 576P, 720P, 1080I, 1080P

VGA

Format

up to 1920*1200

Line frequency

31.5~94.038KHz

Field

60~75Hz

Interface

D-SUB15

AUDIO INPUT

VGA Audio

L/R Audio Input

AUDIO OUTPUT

Max Output Power

2*2W(4Ω)/2*1.6W(8Ω)

Headphone Output

5mW-10mW(32Ω)

POWER

DC Input

12V

Panel Voltage

3.3V/5V/12V

Standby Consumption

< 0.25W

OSD LANGUAGE

Chinese, English, Korean, etc.

KEY FUNCTION

POWER, MINUS, PLUS, MENU, EXIT, up(Optional), DOWN(Optional)

No

Function Descriptor

No

Function Descriptor

1

HDMI Input

8

ADC Expansion Connector

2

DVI Input

9

Panel LVDS Connector

3

VGA Input

10

Panel Supply Voltage Select

4

Audio Input

11

Backlight Control and Power Supply Connector

5

Earphone Output

12

Speaker Connector

6

12V DC Input

13

Built-in 12V Connector

7

Keyboard Connector

14
