the following example is for you reference.


1.Brief Introduction:

this production line is special for making frozen French fries in small scale.  100kg/h,200kg/h and 400kg/h,three capacity model for your choice.
Processing Steps of Small Scale Frozen French Fries Line

2.Techincal parameters:



Name	Parameters
1.Potato Washer and Peeler Machine	Power:1.5Kw  Voltage: 380V-3/220V-3    Weight:180KG Size:1400*850*800mm Capacity:600KG/H
2.French Fries cutter	Power: 1.1kw   Voltage:380v-3/220v-3 Weight: 110KG Size: 950*900*1000mm Capacity: 600KG/H
3.Blanching Machine	Model:GG-20 Power:48 kw Voltage:380V-3/220V-3 Capacity:200 kg/h Weight:140kg Dimension:2200*700*950mm
4.Dewater Machine	Power: 1.5kw Volts: 380v-3/220v-3     Weight: 390KG Size:1000*600*850mm Capacity:300KG/H
5.Fryer	Model:GG-200A Power:48 kw Voltage:380V-3/220V-3 Capacity:200 kg/h Weight:140kg Dimension:2200*700*950mm
6.De-oiling Machine	Power: 1.5kw Volts: 380v-3/220v-3     Weight: 390KG Size:1000*600*850mm Capacity:300KG/H
7.Flavoring machine	Model:GG-2 Power:1.1 kw Voltage:380V-3/220V-3 Capacity:300 kg/h Weight:190kg Dimension:1100*800*1300mm

3.Performance features:

1. the first step is potato washing and peeling.  Emery lining cleaning & peeling machine or brush type cleaning peeling machine,both of them could finish cleaning and peeling one time,high efficiency and low cost.
2. Potato cutting.  You could cut potato into both slice and bar shape; besides,the thickness and size of them could be adjusted totally as your preference.
3. Thirdly,put the potatoes chips or strips into blanching machine for washing,making them look more attractive.
4. the following step is de-watering in order to save the time of frying and make the products more delicious.
5. Then Fry the potato chips in the water-oil frying machine: this increases greatly the oil's using cycle,saving lots of cost.  What's more,the exact oil temperature guarantees the good quality and taste of potato chips.
6.  De-oiling machine: reduce the oil content of potato chips,make them more delicious.
7.  Freezing machine: made of stainless steel,could make freezing in short time.
