Specification

* Reading/Writing magnetic stripecard complied with ISO formats

* Reading/Writing Drivers Licenses(Cool New!)

* Read/Write High & Low Coercive(300~4000Oe)

* High/Low Coercivity encoding circuitryselectable on screen

* Program software for Windows98/Me/XP/Vista

* Programming software for various read/writeperformance

* Can be use directly with Mini123ex etc

* Pure USB directly

* +9VDC, 2.5AMax external power adapter attached,Smaller than others

* DimensionsSmaller than others

* Exeba software support

Dimensions of Box 290(L)x 180(W) x 100(H) mm

Electrical

Powerrequirements+9VDC +/- 5%

ConsumptionTypical 350mA Max.600mA plus for each writing track

PowersupplyExternal switchingpower 9V/2.5A

CommunicationStandard RS232 or USB withUSB-to-RS232

Ripple50mVp-p or less

Dielectric strength500 VDC for 1 minute

Performance

Read card Track1 Track2 Track3

Bit per density210 bpi75/210bpi210 bpi

Coercive forceRead/write 300-4000 oe Mag.Card

Card thickness0.76-1.2mm

Read speedSTD cardJitter +/-15%Amp. 60%

5-55ips5-50ips5-50ips

Write speed5-30ips

Write jitterInterval < +/- 10%, Sub-interval< +/- 12%

Error rateRead < 0.5%Write < 0.8%

Head lifeMin. 1000K swipes for both read/write head

Rate

CE,FCC, UL,CUL
