Type: | Ventilation |
---|---|
Brand Name: | DACO |
Certification: | ISO9001:2015 |
Size: | 52mm-610mm |
color: | silver |
Model Number: | DEC-IA |
Place of Origin: | China (Mainland) |
Temperature: | -30 to +120 |
Specification: | 76 to 508 |
Insulation: | glassfiber/polyester |
Air Velocity: | Max.25m/s |
Pressure: | Max.2500Pa |
Packing: | compressed into a duct |
Quick Details
Specifications
HVAC systems Insulated flexible duct 8 inch thermal Aluminum Flexible air Duct
Insulated Flexible Aluminum Foil Duct: (DEC-IA)(with seamless outer jacket)
the inner flexible duct is aluminum Foil/polyester covered with 25mm 16kg/m3Fiber glass wool and outer jacket made of aluminum foil and polyester Film. the outer jacket is seamless.
the insulated aluminum flex duct consists of an aluminum laminate inner duct, thermally insulated with a glass wool layer and provided with an aluminum laminated outer jacket.
the thermal insulation is suitable for
Preventing condensation and minimizing heat loss and loss of cold.
Specifications:
Diameter Range: 52mm~610mm
Temperature Range: -30 to +150
Operating Air Velocity: 30m/s
Operating Pressure: Max.+3000Pa
Bending Radius: Min.0.54×D
Standard Length: 10m
Reaction to Fire: Difficult to ignite
Packing: Single cardboard box
Construction
1.Inner duct: AL foil
2.Glass wool blanket: 25mm,16kg/m3
3.R-value: 0.65k/w
4.Outer jacket: twisting seamless AL foil
5.Appearance: silver jacket,PVC jacket
Application
Insulation in air supply systems
Air conditioning systems
Thermal insulation in order to prevent heat or cold loss
Prevention / removal of condensation
Installation:
Usage:
HVAC air condition system
Ventilation system
Company Information:
DEC Mach Elec&Equip (Beijing) Co.,Ltd.(" Dec Beijing" ) is an exclusively foreign-owned enterprise formed by Holland Environment Group Company (" DEC Group" ) in 1996 and with an Amount of RMB ten million and five hundred thousand of registered capital.
DEC Group, one of the largest Manufacturers of flexible duct in the world, is a transnational corporation Specializing in manufacture of various kinds of ventilation ducts. Its products of flexible ventilation duct have passed quality certification tests in more Than 20 countries such as American UL181 and British BS476.
by using a full set of automated Production line of DEC Group and its product specifications and manufacturing Techniques, DEC Beijing, manufacture nine major species ventilation flexible Ducts, such as Aluminum foil duct,Combined PVC and AL foil duct,Insulated duct and acoustical and thermal ducts applying for Ventilating and exhausting systems in high, medium or low pressures, or Erosive, high-temperature, heat-insulation environments.
Annual output of flexible ducts of DEC Beijing is five hundred thousand(500,000)ms, amounting to circle more than ten Times of the circumference of the earth. for more than ten years of development In Asia, now Dec Beijing focus on supplying high quality flexible ducts to a Variety of industries such as building, nuclear energy, military, electron, Space transportation, machinery, agriculture, steel refinery in China or Overseas market.
Wherever there is gas transportation, There will appear our products. Dec Beijing have already become one of the Leaders in domestic construction ventilating and industrial flexible ducts.
FAQ:
Are you factory or
Trade company?
We are factory founded in 1996.
Could i be your agent?
Yes,agent can accept.
