1.Hardened guideway
 2.Taiwan high speed turret milling head
 3.X.Y & Z axis auto feeding
4.Milling Machine has added 45 degree swivel table

5.Large torgue and strong power, fast moving is 2000mm/min

Specifications	X6336WA
Spindle taper	ISO40V ISO50 H
Arm travel	500
Spindle speed range(r.p.M)	68-7200 V 60-1800 H
Table size	1630*360
Table travel	1000*300*405
Main motor(kw)	4.0 H 3.7/2 (V)
Distance from vertical spindle to table surface(mm)	135-485
Distance from horizontal spindle to table surface(mm)	0-350
Overall dimensions(mm)	2000×2000×2250
N.W/G.W (kg)	2650/2850
