| Operating Temperature: | -10C~60C |
|---|---|
| Supply Voltage: | 2.8V |
| Application: | Watch |
| Type: | Drive IC |
| Brand Name: | CNK |
| Model Number: | CNKT0096 |
| Place of Origin: | China (Mainland) |
| Type: | TFT |
| LCD Type: | TFT Transmissive |
| Viewing Direction: | 12 :00 |
| Module outline(W*H*D): | 26.7*19.26*1.6 |
| Active area(W*H): | 21.744*10.864 |
| Number of Dots: | 128(RGB)*64 |
| Colors: | 262K |
| Backlight Type: | 1 LED |
| Interface Type: | System parallel or Serial interface |
| Input voltage: | 2.8 |
Quick Details
Specifications
HuiZhou CNK Electronics CO.,LTD.
Model Number:CNKT0096
LCD Type:TFT Transmissive
Viewing Direction:12 o'clock
Module outline(W*H*D):26.7*19.26*1.6
Active area(W*H):21.744*10.864
Number of Dots:128(RGB)*64
Colors:262K colors
Backlight Type:1 LED
Interface Type:System parallel or Serial interface
Input voltage:2.8V
Operating Temperature:-10C~60C
Storage Temperature:-20C~70C
Model Number:CNKT0096
LCD Type:TFT Transmissive
Viewing Direction:12 o'clock
Module outline(W*H*D):26.7*19.26*1.6
Active area(W*H):21.744*10.864
Number of Dots:128(RGB)*64
Colors:262K colors
Backlight Type:1 LED
Interface Type:System parallel or Serial interface
Input voltage:2.8V
Operating Temperature:-10C~60C
Storage Temperature:-20C~70C
