JT3105 Visual Fault LocatorIs used for the measurement in single-mode or multi-mode fibers. It features a rugged design, an universal connector and an accurate measurement. the JT3105 visual fault locator easily identifies the cutting, micro-bending of the optic fiber, passes through the jacket fiber and performs an end-to-end fiber identification. Its measurement range is up to 5km. It is an ideal tool for the examination of all kinds of patch cords and ribbon or bunched pigtails in the installation and maintenance of fiber optic networks.

Pictures of JT3105 Visual Fault Locator

Features:

1. Detects breaks, micro-bends even through jacketed fibers

2. End-to-end visual fiber identification

3. Locates faults up to 5km along the fiber.

4. Mechanical fusion splice optimization

5. Compact size and light weight, suitable for field testing



Applications:

• Maintenance in Telecom

• Maintenance CATV

• Fiber Optic Lab Testing

• Other Fiber Optic Measurements



Specifications:

Type	JT3105
Wavelengths(nm)	650±10nm
Fiber   Model	SM,MM
Output   Power	1mw
Spectral   Width(nm)	≤5
Emission	CW, 2Hz can be optional
Optical   Connector	FC/ Universal 2.5mm adaptor
Power   Supply	2pcs AA alkaline batteries
Battery   Operating Time	30 hours
Operating   Temperature(℃)	-10~+60
Storage   Temperature(℃)	-25~+70
Dimension(mm)	108x52x20
Weight   without battery (g)	56

Remark: Pen-type VFL can be provided!



Standard Packages:
